AVAYA IP Office ตู้สาขาโทรศัพท์

By 22 กุมภาพันธ์ 2017กรกฎาคม 8th, 2022A/V, UC & Conference, Networking & Security, Solutions
avayaipo

AVAYA IP Office สำหรับระบบ IP Telephony ของคุณ

#iptelephony #ipphone #ippbx #callmanager #ตู้สาขาโทรศัพท์

AVAYA IP Office เป็นระบบโทรศัพท์แบบไฮบริด ซึ่งรองรับทั้งระบบ Analog ระบบ Digital และ IP Telephony ที่มี PBX functional capabilities ครบ เราสามารถทำการติดตั้งจากขั้นพื้นฐานที่ 5 extension(หมายเลขภายใน) และขยายได้มากในภายหลัง นอกจากนี้ AVAYA IP Office ยังมาพร้อมระบบตอบรับอัตโนมัติ (Auto Attention/IVR), ระบบบันทึกเสียงการสนทนา, มี Soft phone, มี log บันทึกการใช้งาน และรองรับการใช้งานกับ SIP Phone, IPPhone หรือ โทรศัพท์ธรรมดา

AVAYA IP Office Platform  เป็นระบบที่คุ้มค่าแก่การลงทุนอย่างมาก เพราะออกแบบระบบแบบ Modular ทำให้สามารถประกอบอุปกรณ์รวมกันเป็นระบบโทรศัพท์ที่เหมาะและตรงกับความต้องการได้ ทั้งยังสามารถเพิ่มคุณสมบัติได้โดยการอัพเกรดซอร์ฟแวร์ รองรับการใช้งาน Mobile (ต้องเตรียมความพร้อมระบบเครือข่าย) และการกระจายของผู้ใช้งาน ที่รองรับทั้งเสียงและวิดีโอ แทบจะทุกอุปกรณ์ โดย AVAYA IP Office นั้นรวมเอา โซลูชั่นในการสื่อสารหลากหลายไว้ด้วยกันและรองรับการขยายได้ถึง 3000 Extension(หมายเลขภายใน) เชื่อมต่อได้ถึง 150 Site ในเครือข่ายแบบ Multi-Site มาพร้อมสเถียรภาพ ตอบโจทก์ทุกความต้องการ ตั้งแต่ ความต้องการขนาดเล็กแบบกล่อง Appliance ง่ายๆ ไปถึงระบบโทรศัพท์ แบบ Virtualization ในศูนย์ข้อมูล และยังมีทางเลือกเพิ่มเติมให้เลือกใช้ มากมาย สร้างประสบการณ์การสื่อสารสำหรับผู้ใช้ ที่มีทั้งประสิทธิภาพ ทรงพลัง และเข้าถึงได้ ทำให้ AVAYA เป็นผู้นำในอุตสาหกรรม ซึ่งคุณสามารถให้ความไว้วางใจและเชื่อถือได้

Enterprise Grade

AVAYA IPO Plateform เป็นสินค้าเกรด Enterprise รองรับการทำงาน 10+ ปี และมีอะไหล่ให้บริการตลอดอายุผลิตภัณท์ โดยผู้ใช้สามารถซื้อ Maintenance Service เพื่อรักษาระดับของบริการ ให้ระบบสามารถใช้งานได้ตามระยะเวลาโครงการที่ผู้ใช้ต้องการ
ด้วยที่ผลิตภัณท์ เป็น Modular เมื่อมีการอัพเกรดจึงไม่จำเป็นต้องเปลี่ยนอุปกรณ์ยกชุด เพียงอัพเกรดเพิ่มเติมบางส่วนหรืออัพเกรดเฉพาะซอร์ฟแวร์ ผู้ใช้ก็ได้ใช้เทคโนโลยีล่าสุดทันที

คุณสมบัติพื้นฐาน ระบบ IP Telephony จาก AVAYA

การบริหารจัดการ

  • รองรับการบริหารจัดการผ่าน Web และ ผ่าน Management Application

สายนอก

  • Analog Line Trunk (ใช้จำนวนมากต้องใช้ ควบคู่กับ IP500 External Expansion Modules)
  • E1 Trunk (ใช้จำนวนมากต้องใช้ ต้องใช้ ควบคู่กับ IP500 External Expansion Modules)
  • SIP Trunk

สายใน

  • Analog Extension (ใช้จำนวนมากต้องใช้ ต้องใช้ ควบคู่กับ IP500 External Expansion Modules)
  • Digital Extension (ใช้จำนวนมากต้องใช้ ต้องใช้ ควบคู่กับ IP500 External Expansion Modules)
  • IP Extension (รองรับทั้ง SIP, H323 Protocal)

เลือก Platform ที่เหมาะกับคุณ

  • H/W Appliance (AVAYA IP Office 500v2)
  • Virtual Appliance (OVA ติดตั้งบน VMware หรือ Hyper-V)
  • Server (ISO image ติดตั้งบน Physical Server)

AVAYA IP500 V2/V2A System Components

IP500 V2/V2A Control Unit
The IP500 V2/V2A control unit is a stackable unit with an optional 19″ rack mounting kit and optional wall mounting kit for smaller configurations. The IP500 V2/V2A control unit has 4 slots for the insertion of base cards.

IP500 External Expansion Modules (รุ่นที่ใช้บ่อย)

ข้อมูลสำหรับ IP500 External Expansion Modules ทั้งหมด >>

IP500 Analog Trunk 16
The IP500 Analog Trunk module can be used to add 16 additional analog trunks to an IP Office system. The module supports both loop-start and, with suitable grounding, ground-start trunks.

IP500 Digital Station 16/30
IP Office 500 Digital Station modules can be used to add additional DS ports to an IP Office system for support Avaya DS digital telephones. The module is available in 16 and 30 port variants, referred to as the IP500 DS16 and IP500 DS30 respectively. These modules are also known as IP500 DS V2 modules.

IP500 Phone 16/30
IP500 Phone modules can be used to add additional PHONE ports to an IP Office system. The module is available in 16 and 30 port variants, referred to as the IP500 Phone 16 and IP500 Phone 30 respectively.

IP500 Base Cards (ใช้บ่อย)

ข้อมูลสำหรับ IP500 Base Cards ทั้งหมด >>

IP500 V2/V2A ATM Combination Cards

10 voice compression channels. Codec support is G.711, G729a and G.723 with 64ms echo cancellation. G.722 is supported by IP Office Release 8.0 and higher.

6 Digital Station ports for supported Avaya DS digital telephones (except 3800 Series).

2 Analog Extension ports.

4 Analog Trunk ports

IP500 Analog Phone Base Cards
This card is used to add analog phone ports to the control unit. It is available in two variants, providing either 2 or 8 analog extension ports.

Provides either 8 or 2 analog phone ports depending on card variant

IP500 VCM Cards
This type of card is used to add voice compression channels to the control unit. Those channels are used for VoIP calls including IP extensions and or IP trunks. IP500 V2/V2A control units support up to 148 voice compression channels

Codecs G.711, G.729ab and G.723 with 64ms echo cancellation. The maximum number of simultaneous channels useable on an IP500 VCM base card is affected by the codec being used. The following table assumes that all calls using the VCM use the same codec. Note: Whilst IP500 VCM cards support G729b, it is not supported by other IP Office systems such as Linux based systems.

G.722 is supported by IP Office Release 8.0 and higher in systems with an IP500 VCM card or an IP500 Combination card.

Codec

IP500 VCM 32
IP500 VCM 32 V2

IP500 VCM 64
IP500 VCM 64 V2

G.711

32

64

G.729ab

30

60

G.723

22

44

G.722

30

60

IP500 Trunk Daughter Cards

สำหรับผู้ใช้ที่ยังต้องการใช้งาน E1 Trunk สามารถเพิ่ม Module ไปบน Base Card ข้างต้นได้ โดยใช้ IP500 Trunk Daughter Card >>

EZ PackageGood choice

฿ 7000

Per Monthระบบโทรศัพท์แบบไอพี 100%

  • 1 x AVAYA IP Office 500v2
  • Firmware : Preferred Edition
  • 1 x PoE Switch

ติดตั้งยังสำนักงานของลูกค้า (สำหรับ Onevois – ITSP ลูกค้าจำเป็นต้องจัดเตรียม Internet ไว้เพื่อใช้บริการ)

Asset Lover

฿ Call

PerpeptualCustomized base on customer requirement

Maintenance Service Agreement Available for purchase separately

ค่าบริการรายเดือน ประกอบไปด้วย 4 ส่วนคือ

  1. ค่าเช่าเลขหมายสำหรับสายนอก*
    เบอร์ 02 เบอร์ละ 200 บาท คู่สายละ 120 บาท (เริ่มต้นที่ 1 เบอร์ 5 คู่สาย) กรณีใช้ Onevois – ITSP
  2. ค่าโทร ตามใช้งานจริง กรณีใช้ Onevois – ITSP
  3. ค่าเช่าระบบตู้สาขาโทรศัพท์ตาม Package
  4. ค่าเช่าเครื่องโทรศัพท์ รุ่น AVAYA J139 เครื่องละ 150 บาท

*รองรับสายนอกจากผู้ให้บริการหลัก(Main ITSP) ทั้ง NT(Former TOT), True อื่นๆ
– ผู้ใช้บริการชำระค่าบริการข้อ 1-2 กับผู้ให้บริการโดยตรง ไอดินนายด์ จัดเก็บค่าบริการเฉพาะข้อ 3-4

อัตราค่าโทรศัพท์ภายในประเทศ

ตารางอัตราการโทรระหว่างประเทศ

ค่าบริการจะจัดเก็บหลังใช้บริการ (รายเดือน/รายปี) โดย บริษัท ไอดินนายด์ จำกัด
โดยใบกำกับภาษีและใบเสร็จรับเงิน(ตัวจริง)จะจัดส่งทางไปรษณีย์หลังชำระค่าบริการ ตามรายละเอียดในใบแจ้งหนี้ที่จัดส่งทางอีเมลล์แก่ผู้ใช้บริการ
